AN SP11-15W IP PA Speaker
AN SP11 15W IP PA Speaker – Wall Mounted
The IP PA Wall Speaker offers versatile installation options, allowing it to be mounted horizontally or vertically on building exteriors, such as under eaves. It’s an excellent choice for schools, offices, retail spaces, and hospitals. This speaker is perfect for playing background music, making announcements, or linking with nurse calls and security and fire alarm systems. With support for the standard SIP protocol, it seamlessly integrates with other SIP devices, while the ONVIF protocol ensures compatibility with most IP camera VMS/NVR brands on the market.
Features:
- IP 55 waterproof design for installation on the exterior of the building
- PoE eliminates the need for a local power supply
- 48K OPUS Audio Codec enables excellent sound quality
- Supports web firmware upgrade for easy maintenance
- Standard SIP protocol to compatible with other SIP devices
- Compatible with IP Camera VMS/NVR via ONVIF
- Supports Pre-recorded messages
- Supports HTTP API for alarm
- Supports RTP Multicast as an alternative to a SIP backend system
Specifications
| Audio | |
| Codec | OPUS 48K, MP3 44.1 kHz, G.722 ADPCM 16 kHz, G.711 PCMU 8 kHz, G.711 PCMA 8kHz |
| Speaker | |
| Max SPL | 101dB |
| Frequency Response | 80Hz ~ 20KHz |
| Network | |
| Security | Password protection, IP address filtering, Digest authentication, User access log |
| Network Protocol | SIP, ONVIF, HTTP, IPv4, DHCP, RTSP, RTP, RTCP, TCP, UDP, ARP, FTP, TFTP, NFS, NTP |
| Network Interface | 10/100 Base-TX, RJ45 |
| VoIP | 2 SIP Accounts SIP Direct IP CallRTP Multicast |
| Amplifier | |
| Amplifier Description | Built-in 15W Amplifier |
| General | |
| Material | ABS (IP55 water-proof) |
| Rate Power | 15W |
| Power Supply | PoE or DC 12V |
| Installation | Wall Mounted |
| Dimensions | 296 x 196 x 157 mm |
| Weight | 3 KG |
| Languages | English |
| Warranty | 1 year |
| Package Includes | Wall Mount IP Speaker Quick Start Guide |
