AN1912 4G LTE Video Intercom

AN1912 4G LTE Video Intercom – Experience Wireless Communication with no wiring required and no WiFi Issues

The AN1912 4G LTE Video Intercom is suitable for up to 1000 existing apartments as well as new builds. It operates on a 4G network or Wired Network and can be configured by the mobile APP (IOS App or Android App)

AN1912 Product Sheet

Aristel-AN1912-Quick-Install-Guide

RECOMMENDED : ANMAG5G ANTENNA FOR FURTHER RANGE

OPTIONAL :  RAINHOOD ACCESSORY DC-046 Aristel-DC-046-RainHood-for-AN1912-ProductSheet

Features:

• 4G IP Videophone
• Instant video call to mobile app
• 24/7 video recording
• Face Detection Alarm
• Max. 1000 room numbers
• Max. 1000 Mifare cards (optional)
• Max. 2000 PIN Codes
• 4G LTE Network
• 1080p H.265 video
• 2-way audio
• SD Card Storage up to 128GB
• Power: DC 12V-18V 1A

Advantages:

• No complex or expensive cabling installation costs
• Quick installation – only requires AC/DC power
• Low running costs with minimal power consumption
• High quality video and digital audio
• Fast speeds
• Can operate from any location where mobile coverage exists
• Data usage = 1MB per min (typical); data usage only as required
• Free Mobile App
• Australian Hosted Server (for Aristel Intercoms)

Specifications:

Video:

• Image Sensor:  1/2.7″ 2MP CMOS
• Image Compression: H .265
• Image Frame Rate: 25fps maximum
• Resolution: 1080P (1920 x 1080), VGA (720 x 576)
• Lens: 2.8mm
• Angle of View: H: 90°  V: 80°

Audio:

• Audio Input: Omnidirectional microphone
• Audio Output: Built-in Speaker
• Bidirectional Talk: Dual-way bidirectional talk
• Audio Compression: AMR

Display:

• Seven-Segment Display: 5 Digits

Storage:

• SD Card Type: Micro SD Card Slot
• SD Capacity: 128 GB

Network:

• Ethernet: 10/100 Mbps (PoE Optional)
• Mobile Network: 4G LTE/3G/GSM

Call:

• Video Call: Android and IOS App
• Voice Call: Mobile voice call

Door Release:

• Unlock Door: Remotely by APP, voice call DTMF, PIN Code and/or Mifare card
• Relay Outputs: 2
• Exit Button Input: 1
• Detector Input: 1
• Relay Type: NO & NC
• Relay Time: 1~7 sewconds
• Relay Load: 120V AC/24V DC/10A

Operation Mode:

• Keypad: Mechanical Button
• Reader: Type A Mifare Card

Alarm:

• Face Detection:  Record 10s video clip
• Notification: Alarm, Warning, Notification

Power:

• Power Supply: DC 12V~18V 1A
• Power Consumption: 10 Watts (max.)

Environment:

• Operating Temperature: -10 to +50°C (+14 to +124°F)
• Operating Humidity: 10~80% RH
• Storage Temperature: -20°C to 60°C (-4°F to 140°F)
• Storage Humidity: 0~90% RH

General:

• Reset: Reset Button
• SIM Card: Micro SIM card slot
• Material: Aluminium
• Waterproof: IP54
• Product Dimension:  276 (H) x 116 (W) x 50 (D) mm
• Net Weight: 2.5kg

Property Management Services (PMS)

PMS:

• Property Console
• Property Management
• Access Control
• Security Device
• Fire System
• Tenants
• Visitor Management

Subscription:

• User Management
• Alarm System
• Maintenance
• Application
• User Log

Company Management:

• Company Information
• Service Information
• System Configure
• System Log

Additional Service Module (ASM)

Notification:

• Push Message
• Message Record
• Phone Call
• Call Record

Cloud Storage:

• Video Management
• Face Database

APP (Door Intercom for IOS or Android)

• Add/delete/modify user’s room number/phone number/password/Mifare card
• Unlock door remotely via APP
• Manage multiple devices
• Play video record
• Check log of unlocking
• Door unlock/lock notifications and offline alert to APP

RECOMMENDED : ANMAG5G ANTENNA FOR FURTHER RANGE OPTIONAL :  RAINHOOD ACCESSORY DC-046
